Multitronic MT-6 – electrotherapy, laser and ultrasound unit

Multitronic MT-6 combines two-channel electrotherapy with laser therapy and ultrasound in one unit.

Key features

• two treatments can be carried out at the same time
• combination therapy treatments possible
• 4,3” colour graphic touch screen
• operated by buttons or touch screen
• ergonomic, lightweight treatment probes
• modern design of the unit and probes
• preset treatment programmes for common conditions
• custom programmes saved by the therapist via an on-screen keyboard
• every treatment parameter adjustable individually
• fan control that minimises noise and power consumption
• counters for treatment time and number of treatments performed
• can be used as a portable unit

Standard equipment

• user manual
• complete set of electrotherapy accessories
• E-S 50 flat silicone electrode with P-50 viscose pad (4 pcs)
• E-A 75 flat aluminium electrode with P-75 viscose pad (4 pcs)
• K-2L electrode connection cable (2 pcs)
• O-R1 strap, 50 x 500 mm (2 pcs)
• O-R2 strap, 50 x 800 mm (2 pcs)
• mains cable
• fuse T-0.315AL, 250 V (2 pcs)
• warning labels for the door
• ultrasound gel 0,5 l (when an ultrasound head is ordered with the unit)

Optional equipment

• electrotherapy accessories
• laser probes
• ultrasound heads
• protective goggles for laser treatment
• floor stand for shower probes
• carrying bag
• trolleys for units and applicators

Technical data

• Power supply: single-phase mains ~230 V ±10%, 50 Hz, 70 VA
• Electrical protection class: class I, type BF
• Ambient temperature: 10°C - 40°C
• Relative humidity: up to 85%
• Dimensions: 335 x 270 x 125 mm
• Control unit weight: 3,4 kg

The unit ships with a green housing as standard. A different colour must be specified when ordering; grey-silver is available at no extra charge.
